Auricular Cartilage Interposition Arthroplasty in Recurrent Temporomandibular Joint Ankylosis in Pediatric Patients

Ahmad Liaquat1, Arun Kumar Shah2, Nabeela Riaz3

1 Assistant Professor, Department of Oral and Maxillofacial Surgery, University College of Medicine and Dentistry, University of Lahore, Pakistan
2 Senior Lecturer, Department of Oral and Maxillofacial Surgery, Chitwan Medical College, Nepal
3 Professor & Head, Department of Oral and Maxillofacial Surgery, King Edward Medical University, Lahore, Pakistan

Background: Temporomandibular joint (TMJ) ankylosis in early childhood can lead to disturbances in growth, facial asymmetry and difficulties in eating as well as in breathing. The objective of the study was to evaluate the effectiveness of auricular cartilage as an interpositional material after gap arthroplasty in pediatric patients with temporomandibular joint ankylosis in maintaining the achieved postoperative mouth opening.
Material and Methods: This prospective study was conducted at the Oral and Maxillofacial Surgery Department of King Edward Medical University, Lahore, from 1st January 2019 to 30th November 2019. Thirty patients, aged 5 to 15 years with clinical and radiological diagnosis of TMJ ankylosis were included in the study. TMJ ankylotic mass was removed, the gap was created and interposition of auricular cartilage graft was done in these patients. Mouth opening was measured as a distance between the incisal edges of mandibular central incisors to maxillary central incisors using the scale. Preoperative and postoperative mouth opening was noted and compared using the paired t-test.
Results: Among the thirty patients, 19 were male and 11 were female. The mean (±SD) age of patients was 9.23±3.23 years (age range 5 to 15 years). The mean preoperative mouth opening (T1) was 7.3±3.1 mm, while the mean postoperative mouth opening (T2) was 29.2±3.3 mm. The mean interincisal distance was 29.0 mm (range 21 mm to 35 mm). The mean difference in pre- and postoperative mouth opening (T2-T1) was 21.6 ± 5 mm.
Conclusions:Autogenous auricular cartilage graft is an efficient and reliable interpositional material for achieving early postoperative mouth opening in TMJ ankylosis patients.
Key words: Auricular cartilage graft, Temporomandibular joint ankylosis, Trismus.

Temporomandibular joint ankylosis (TMJ) is characterized by difficulty or limited mouth opening. TMJ ankylosis is associated with feeding problems, occlusal disharmony, upper airway obstruction, inability to maintain oral hygiene, dental caries, and facial asymmetry in developing children1. In TMJ ankylosis, the condyle of mandible fuses with the articular surface of the temporal bone and limits the mouth opening. Development of TMJ ankylosis in childhood causes facial disfigurement, nutritional imbalances due to inability to eat food and psychological problems1 Trauma to the mandible or TMJ is the leading cause of ankylosis in paedriatic population (13-100%)2. Other etiological factors include systemic or local infection (40%) or systemic diseases (10%), such as rheumatoid arthritis, ankylosing spondylitis, and psoriasis in the adult patient.2 Orhan Guven described a higher rate of post-traumatic ankylosis in children3. A study conducted in Pakistan showed peak incidence of TMJ ankylosis in 6-10 years and the most common causes for TMJ ankylosis were reported as fall (82.8%) and dysphonia (66.7%) due to impairment of upper airways. Dysphasia, facial deformity, and psychological disturbances are consequences of TMJ ankylosis2, 4.
Treatment of TMJ ankylosis is very challenging because of frequent recurrences5. However, gap arthroplasty and insertion of interposition material to prevent re-ankylosis is the mainstay of treatment. Gap arthroplasty without interposition results in recurrence of ankylosis in almost 53% of patients2. Timing of the surgery and choice of the interposition material may vary from center to center, but the main treatment is the same. Interpositional materials separate the condylar area from the glenoid fossa, so their anchorage and viability are very important6.
Various types of interposition materials have been used in the literature for augmentation of height of ramus and prevention of re-ankylosis. These materials are autologous grafts (rib grafts, auricular cartilage, temporalis fascia etc.) and alloplastic material (silastic material, custom-made titanium condylar prosthesis etc.). Temporalis fascia with or without temporalis muscle is the most commonly used interpositional material because of its proximity to the operating site and being a pedicled flap, it can resist the wear and tear forces7, 8.
Auricular cartilage is another reliable graft present very close to the operating site and has been used as an interposition graft after TMJ ankylosis surgery with good results8. The main advantages include safety, viability, preserving the function of the condyle, non-antigenicity and low donor site morbidity. Availability of auricular graft adjacent to the surgical field makes it the most attractive choice for surgeons9. Auricular cartilage is fixed to the condyle by sutures.
The rationale of this study was to evaluate the auricular cartilage as an interpositional material in terms of maintaining the postoperative mouth opening. Although different types of autogenous graft and alloplastic material are used for interposition, no material has produced uniformly successful results. Limited data is available on the use of auricular cartilage as an interpositional material in recurrent TMJ ankylosis cases. Moreover, a previous study using auricular cartilage was conducted on a small number of patients (n=10)9. So the present study was designed to generate more reliable results for our local population.

This prospective study was conducted at the Oral and Maxillofacial Surgery Department of King Edward Medical University, Lahore, Pakistan from 1st January 2019 to 30th November 2019. Approval for the study was obtained from the ethical review board of the university (Reference number 1697/18). Patients aged 5 to 15 years with unilateral and bilateral or recurrent TMJ ankylosis were included in the study. Patients with an ear deformity or medically unfit for surgery were excluded.
After explaining the outcome of surgical procedures to every patient, informed consent was taken from their parents/guardians before the scheduled surgery. To diagnose TMJ ankylosis, orthopantomograms and computer tomography was done. For removal of fibrous adhesions or ankylotic mass, preauricular incision was used. Dissection was done layer by layer to reach up to the ankylotic mass, preserving the zygomatic and temporal branches of the facial nerve. Ankylotic mass was removed and auricular cartilage graft was harvested from the posterior aspect of the helix. The auricular cartilage was secured with condyle using proline sutures. Postoperative management was done in the ward until the removal of sutures. Mouth opening was measured from the incisal edges of mandibular central incisor to maxillary central incisor by the scale. Mouth opening was measured preoperatively (T1) and recorded. Postoperative mouth opening was measured after three months (T2). The mean difference of mouth opening (T2-T1) was calculated for each patient, using the paired t-test with P-value < .05 considered as statistically significant.

Among the thirty patients included in this study 19 were males and 11 were females. The mean (± SD) age of the patients was 9.23 ± 3.23 years. The mean preoperative mouth opening (T1) was 7.3±3.1 mm. There was no significant difference among male and female patients in terms of preoperative mouth opening (P = .29). The mean postoperative mouth opening (T2) was 29.2 ± 3.3 mm, with no significant difference among male and female patients (P = .99). The mean difference in pre- and postoperative mouth opening (T2-T1) was 21.6 ± 5 mm, which was statistically significant (P < .001). Seventeen patients (56.66%) had unilateral TMJ ankylosis with 58.82% (n=10) having right-sided and 41.17% (n=7) patients having left-sided TMJ ankylosis. Thirteen patients (43.33%) had bilateral TMJ ankylosis. The most common cause of TMJ ankylosis was history of fall (80%), followed by roadside accidents (13.33%) and birth trauma (6.67%).

Table I: Gender wise comparison of pre- and postoperative mouth opening



Male

Female

Mean Age (years)

9.47 ± 3.2

8.82 ± 3.4

Mean preoperative mouth opening (mm)

7.6 ± 3.5

7.8 ± 2.4

Mean post-Operative mouth opening (mm)

29.8 ± 3.3

28.2 ± 3

Mean difference in mouth opening

22.3 ± 5.7

20.4 ± 3.2

Paired t value

-22.3

-20.4

95% CI

-25.0 to -19.5

-22.5 to -18.2

P-value*

< .001

< .001


*P-value < .05 was considered statistically significant

Table II: Duration of TMJ ankylosis

Duration of ankylosis (years)

n (%)

1-2

8 (26.67)

2-4

13 (43.33)

>5

9 (30)

Total

30

This study aimed to evaluate auricular cartilage as an interpositional material in gaining the postoperative mouth opening. TMJ is a main part of the joint of the temporal region. Ankylosis of the joint in a growing child may result in disfigurement of the face, difficulty in eating, speech, and maintaining oral hygiene. TMJ ankylosis can result in retrognathic mandible, causing cosmetic and functional deformities. The main objective of treatment is to correct the jaw opening and prevent the development of disfigurement and psychological distress10.
TMJ ankylosis is classified according to the type of tissue involved (bony, fibrous, or both), location (intracapsular or extracapsular), and extent of fusion (incomplete or complete)11. In children, the head of the condyle is small, so its injury can result in hemarthrosis. Pain causes the hypomobility of the joint, which in turn favors bone formation leading to ankylosis12. TMJ can be infected by infection of the ear or distal spread from scarlet fever or tuberculosis13.
Trauma to the mandible and in the TMJ region is the leading cause of ankylosis in children. Many cases with previous history of trauma to the chin or a history of fall and trauma to jaws in childhood develop trismus later on in life14. They become nutritionally deficient and trismus also poses a great hindrance in maintaining good oral hygiene. So, these patients have severe malaligned teeth and caries. Due to mandibular retrognathism and facial disfigurement, these patients are socially rejected and develop psychological issues.
Many graft materials are available, which can be classified as autologous or alloplastic. Grafts from the clavicle, iliac crest, costochondral, auricular cartilage and dermal fat are considered autologous grafts15. Alloplastic grafts include silicon, protoplast, and acrylic, etc15. Alloplastic material have adverse effects like foreign body reactions, infection, instability, and extrusion. Therefore, alloplastic material is not the preferred choice. Among the autogenous materials, cartilage has many physiological and mechanical advantages. It is available within the same operative field with less donor site morbidity. The study by Krishnan showed that the shape of the cartilage is well-fitting the condylar process, and maintaining its viability thus helping in the condyle function. He reported temporary facial nerve paralysis in two patients9. In our study, temporary facial nerve paralysis was observed in five patients. Postoperative use of steroids resolved the facial injury and only one patient had permanent damage to the frontal branch of the facial nerve. The injury occurred during surgery as branches of the facial nerve were in the course of the surgical site. It was not related to the choice of graft. There was no donor-site morbidity noted in our cases. In this study, 30 patients were included, out of which 63% were male and 37% were female. Ten patients had recurrent TMJ ankylosis. The patients’ age ranged from 5 to 15 years with a mean±SD of 9.23±3.23 years, which is comparable to the study conducted by Gupta et al., where the mean±SD age was 11.1±3.3 years16. Similarly, out of 87 patients reported from the Orthodontic and Oral and Maxillofacial Surgery departments of Khyber College of Dentistry, 63.2% were male and 35.6% were female, ranging from 2 to 16 years1. However, Svensson et al. reported 18 patients with 15 females and three males and a mean age of 39 years17.


Figure 1. A: Preoperative mouth opening. B: Postoperative mouth opening in the same patient.


Figure 2: Exposure of ankylotic mass by preauricular incision.


Figure 3: A shows harvesting of auricular cartilage, while B reveals harvested cartilage.

Krishnan reported the mean preoperative mouth opening to be 2.5 mm in his study while Svensson et al. reported 28 mm9, 17 Muller et al. reported the preoperative mouth opening to be 17 mm in their single patient study18. In the present study, the preoperative mean mouth opening was 7.6±3.5 mm for males and 7.8±2.4 mm for females and the range of mouth opening preoperatively for males and females was 3-15 mm and 4-12 mm respectively with a mean preoperative mouth opening of 7.7 mm. This is somewhat comparable to the study by Krishnan9. but varies considerably from figures reported by Svensson et al. 17.
The mean postoperative mouth opening in our study was 29.2 mm, which is comparable to 29.6 mm reported by Krishnan9. Other studies report variable figures of 5mm (Muller et al.)18 and 35 mm (Svensson et al.),17 respectively. The postoperative mouth opening of all these studies is comparable.9 The similarity in the postoperative mouth opening but the variability in preoperative mouth opening may be because of the time of surgery and duration of TMJ ankylosis. We followed-up our patients for two years, but after that many patients were lost to follow-up.
The most frequent etiology of TMJ ankylosis in the pediatric population is fall history.1 In our study, 80% of patients had ankylosis secondary to fall history. Children do not perform postoperative physiotherapy regularly that resulted in re-ankylosis in our cases. These patients should be put on a long-term follow-up to see re-ankylosis. We found this graft very useful in recurrent cases of TMJ ankylosis where temporalis fascia or muscles have already been used, so we recommend its use in recurrent cases of TMJ ankylosis. Future studies are suggested to explore its long-term effects in maintaining the jaw opening.

An autogenous auricular cartilage graft is good interpositional material for the successful treatment of TMJ ankylosis pediatric patients in terms of achieving adequate postoperative mouth opening.
